Other Phone Features
16
41-001370-00 Rev 01 – 07.2011
Status Lights (LEDs)
The speaker LED, beside the Speakerphone/Headse t key, and the Message Waiting Indicator (MWI) LED, on the
top right of your phone, provide visual indications of your phone’s status.
Speaker LED
Message Waiting Indicator (MWI)
Call Timer
When you make or answer a call, the Timer shows the elapsed time of the call.
Line/Call Appearance Keys
The 6755i has 4 hard line/call appearance keys each with a corresponding status light. Additional line/call appearances
may also be set up on your phone as softkeys.
These line/call appearance buttons and lights represent physical lines or calls for your extension. By pressing a line/call
appearance button, you connect to the line or a call it represents. The line/call appearance light indicates the status of
that line or call.
When the phone is taken off-hook, the phone will automatically select a line for you.
For more information about the Line/Call Appearance keys, see the Aastra Model 6735i IP Phone User Guide.
Speaker LED Status Description
ON Solid Indicates a call is on hands free (speakerphone)
Slow Flash Indicates you are using the headset.
Rapid Flash Indicates the call is muted. Press the Mute key to take the call off mute.
MWI LED Status Description
Slow Flash Indicates you have a message(s)
Rapid Flash Indicates you have an incoming call.
Even Flash Indicates one or more calls are on hold.
Line/Call Appearance LED Status Description
OFF Indicates idle line or no call activity
Rapid Flash Indicates ringing on the line.
Slow Flash Indicates a call is on hold.
