Welcome to the Blue Ox® Experience.
Congratulations on purchasing your SportLoader™. The SportLoader design uses the latest technology and
the highest quality materials. The SportLoader is designed to load and haul a motorcycle in the back of your
pickup truck.
BEFORE using the Overbilt® SportLoader™ manufactured by Blue Ox®, READ THESE INSTRUCTIONS
THOROUGHLY. You will find operating instructions, installation instructions, and safety precautions
enclosed in this owner’s manual. Read these instructions carefully and precisely follow these instructions.
REMEMBER, proper installation and use of this product is the sole responsibility of the user. Improper
installation, use or maintenance may result in malfunction or property damage. Please fill out your warranty
card and mail it back to Blue Ox, or register your product(s) at www.blueox.us. For future reference, your
serial number is located on the back cover of this manual and it is located on your SportLoader tire cradle.
Unpacking your SportLoader TM
Remove the SportLoader from the shipping carton, referencing the parts list on this page or diagram on
page 3. Verify that you have all of the parts BEFORE you start the installation process. If you do NOT,
please contact a Blue Ox dealer or distributor or you can contact a member of Blue Ox’s 24/7 Customer
Care Team at (402)385-3051 or toll free at (888) 425-5382 to order replacement parts. DO NOT use
homemade or non-typical parts.
Page 2 of 7
Parts List
Ref. No. Qty. Part # Description
1 1 61-6155 (SC3000) Weldment Ramp 104” (long box)
61-6195 (SC3001) Weldment Ramp 86” (short box)
2 1 61-6156 Tire Cradle
3 1 61-6152 Weldment, Ramp Extension Mid
4 1 61-6153 Weldment, Ramp Extension End
5 1 61-6190 Bully Jack, Weldment (SC9012)
6* 4 201-0295 5/16-18 x 1 Flat Soc Hs Screw
7* 4 202-0002 5/16-18 Hex Nut, ZP
8* 4 203-0009 5/16 Lock Washer, ZP
9* 4 203-0002 5/16 Flat Washer, ZP
10* 2 270-0061 Cargo Buckle
11* 2 201-0691 7/16-14 x 1 Hex Head Bolt Grade 5
12* 2 202-0002 7/16-14 Hex Nut, ZP
13* 2 203-0003 7/16 Flat Washer, ZP
14* 2 203-0011 7/16 Lock Washer, ZP
15 1 294-0891 Winch, 12volt, No Sprocket
16* 1 294-0892 Solenoid, 12volt
17* 2 201-0691 3/8-16 x 1 1/4 Hex Head Bolt
18* 2 202-0003 3/8-16 Hex Nut
19* 2 203-0004 3/8 Flat Washer
20* 2 203-0010 3/8 Lock Washer
21* 1 229-0705 Gear, 8DP-14.5PA, 20T, 2.75OD, 1.25
22* 2 209-0141 Bearing, 5/8 Flange, Navigator
23* 8 229-0707 Wheel 3
24 2 229-0520 Pin, 1/2 x 2 5/8 EFF
25 2 84-0001 Quick Pin Assembly
26 1 294-0899 Corded Control
* Not visible in the drawing.
SC3000, SC3001
09/06
