Introduction – American Magnetics 188CPS Point-Sensing Instrument User Manual
Page 5

4
Introduction
Rear Panel Layout
1
BNC
coaxial connectors to
oscillator units via the extension cables
2
Relay contacts terminal block
(closed pair = immersed)
3
Input power connector
115/230 VAC 50/60 Hz
S E L E C T O R S W . I N S I D E
O S C 1
O S C 2
O S C 4
O S C 3
O S C 5
A M E R I C A N M A G N E T I C S , I N C .
O A K R I D G E , T N U . S . A .
R E L A Y C O N T A C T S
1
2
3
4
5
1
2
3
