118 |
ﯽﺳﺭﺎﻓ
1 619 929 L76 | (14.8.12) Bosch Power Tools
12 ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﯾﺎﭘ ﻢﯿﻈﻨﺗ ﻞﻔﻗ 10
ﺭﺎﮐ ﻪﻌﻄﻗ یﺎﻬﺘﻧﺍ ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﻪﻌﻄﻗ 11
ﺭﺎﮐ ﻪﻌﻄﻗ ﻪﯾﺎﭘ 12
3 ﻞﻔﻗ ﻡﺎﻤﻀﻧﺍ ﻪﺑ ﯽﯾﻻﺎﺑ ﺏﺎﻗ 13
ﺎﭘ ﻡﺮﻫﺍ 14
« L » ﺥﺮﭼ 15
« R » ﺥﺮﭼ 16
ﻦﯾﺮﯾﺯ ﺏﺎﻗ 17
ﻆﻓﺎﺤﻣ ﺏﺎﻗ 18
ﺐﺼﻧ ﺭﺍﺰﺑﺍ 19
ﻞﻔﻗ ﭻﯿﭘ 20
ﻦﮐ ﻞﻔﻗ ﻪﺤﻔﺻ 21
ﯽﮑﺳﻭﺮﺧ ﻩﺮﻬﻣ 22
24 ﻡﺮﻫﺍ ﻥﺩﺮﮐ ﺩﺍﺯﺁ ی ﻪﻤﮐﺩ 23
ﻩﺪﻧﺭﺍﺪﻬﮕﻧ ﺕﺍﺰﯿﻬﲡ ﻥﺩﺮﮐ ﺖﻔﭼ ﻡﺮﻫﺍ 24
ﻩﺪﻨﻨﮐ ﻒﻗﻮﺘﻣ یﺎﻤﻨﻫﺍﺭ 25
کﺮﺤﺘﻣ ی ﻩﺮﻬﻣ 26
9 ﻞﻔﻗ ﻢﯿﻈﻨﺗ ﻩﺮﻬﻣ 27
20 ﻞﻔﻗ ﭻﯿﭘ ﻢﯿﻈﻨﺗ ﻩﺮﻬﻣ 28
20 ﻞﻔﻗ ﭻﯿﭘ ﻢﯿﻈﻨﺗ ﭻﯿﭘ 29
ﻩﺍﺮﻤﻫ ﻝﻮﻤﻌﻣ ﺭﻮﻄﺑ ،ﺖﺳﺍ ﻩﺪﻣﺁ ﱳﻣ ﺭﺩ ﺎﯾ ﻭ ﺮﯾﻮﺼﺗ ﺭﺩ ﻪﮐ ﯽﺗﺎﻘﻠﻌﺘﻣ ﻪﯿﻠﮐ
ﻪﻣﺎﻧﺮﺑ ﺖﺳﺮﻬﻓ ﺯﺍ ﺍﺭ ﺕﺎﻘﻠﻌﺘﻣ ﻞﻣﺎﮐ ﺖﺴﯿﻟ ﹰﺎﻔﻄﻟ .ﺩﻮﺷ ﯽﳕ ﻪﺋﺍﺭﺍ ﻩﺎﮕﺘﺳﺩ
.ﺪﯿﺋﺎﳕ ﺱﺎﺒﺘﻗﺍ ﺕﺎﻘﻠﻌﺘﻣ
ﯽﻨﻓ ﺕﺎﺼﺨﺸﻣ
GTA 2500 W ﺭﺎﮐ ﺰﯿﻣ
3 601 M12 102 ﯽﻨﻓ ﻩﺭﺎﻤﺷ
1044 mm ﻝﻮﻃ ﺶﯾﺍﺰﻓﺍ ﻪﻌﻄﻗ ﻥﻭﺪﺑ ﺭﺎﮐ ﺰﯿﻣ ﻝﻮﻃ
2510 mm ﻝﻮﻃ ﺶﯾﺍﺰﻓﺍ ﻪﻌﻄﻗ ﺎﺑ ﺭﺎﮐ ﺰﯿﻣ ﻝﻮﻃ
947 mm ﺭﺎﮐ ﺰﯿﻣ ﻉﺎﻔﺗﺭﺍ
180 kg
ﻞﻤﺣ ﻥﺍﻮﺗ ﺮﺜﮐﺍﺪﺣ
(ﺭﺎﮐ ﻪﻌﻄﻗ + ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ)
ﻝﺎﺼﺗﺍ ﺕﺍﺰﯿﻬﲡ –
130
25
kg
kg ﻞﻤﺣ ﻥﺍﻮﺗ ﺮﺜﮐﺍﺪﺣ
(ﺭﺎﮐ ﻪﻌﻄﻗ + ﯽﻗﺮﺑ ﺭﺍﺰﺑﺍ)
ﻝﻮﻃ ﺶﯾﺍﺰﻓﺍ ﻪﻌﻄﻗ ﺎﺑ
ﻝﺎﺼﺗﺍ ﺕﺍﺰﯿﻬﲡ –
ﻝﻮﻃ ﺶﯾﺍﺰﻓﺍ ﻪﻌﻄﻗ ﺮﻫ یﺍﺯﺍ ﻪﺑ –
32,2 kg
ﺩﺭﺍﺪﻧﺎﺘﺳﺍ ﻖﺑﺎﻄﻣ ﻥﺯﻭ
EPTA-Procedure 01/2003
ﺐﺼﻧ
ﯽﻟﺎﺳﺭﺍ ﺕﺎﯾﻮﺘﺤﻣ
ﻝﻭﺍ ﺭﺩ ﯽﻟﺎﺳﺭﺍ ﺕﺎﯾﻮﺘﺤﻣ ﺮﯾﻮﺼﺗ ﻪﺑ ﺭﻮﻈﻨﻣ ﻦﯾﺪﺑ
.ﺪﯿﯾﺎﳕ ﻪﺟﻮﺗ ﺎﻤﻨﻫﺍﺭ ی ﻪﭼﺮﺘﻓﺩ
یﺍﺰﺟﺍ ﻡﺎﲤ ﻪﮐ ﺪﯿﻨﮐ ﻝﺮﺘﻨﮐ ،ﺭﺎﮐ ﺰﯿﻣ ﺐﺼﻧ ﺯﺍ ﻞﺒﻗ
:ﺪﻨﺷﺎﺑ ﻩﺪﺷ ﻝﺎﺳﺭﺍ ﺮﯾﺯ ﺡﻭﺮﺸﻣ
ﺩﺍﺪﻌﺗ ﺕﺎﺼﺨﺸﻣ ﺩﺍﺪﻌﺗ
2 ﻝﺎﺼﺗﺍ ﺕﺍﺰﯿﻬﲡ 1
1 8 ﻩﺎﮔ ﻪﯿﮑﺗ ﺎﺑ ﺭﺎﮐ ﺰﯿﻣ 2
1 3 ﻞﻔﻗ ﻡﺎﻤﻀﻧﺍ ﻪﺑ ﯽﯾﻻﺎﺑ ﺏﺎﻗ 13
1 ﻦﯾﺮﯾﺯ ﺏﺎﻗ 17
1 ﺎﭘ ﻡﺮﻫﺍ 14
1
1
« L » ﺥﺮﭼ
« R » ﺥﺮﭼ
15
16
1 ﻆﻓﺎﺤﻣ ﺏﺎﻗ 18
4
1
2
4
8
4
2
10
4
8
5
4
8
ﻝﺎﺼﺗﺍ ﺕﺍﺰﯿﻬﲡ
:ﻞﻣﺎﺷ
ﺵﻮﮔ ﺶﺷ ﭻﯿﭘ –
M10 x M100
M10 x M55
(ﻮﺷ ﻞﻔﻗ) M10 x M50
M8 x M45
M6 x M45
ﻮﺳﺭﺎﻬﭼ ﭻﯿﭘ –
M8 x M50
ﺮﺷﺍﻭ –
M10 x 29 mm
M10
M8
M6
ﻮﺷ ﻞﻔﻗ ﻩﺮﻬﻣ –
M10
M8
M6
19
:ﯽﻟﺎﺳﺭﺍ ﺕﺎﯾﻮﺘﺤﻣ ﺮﺑ ﻩﻭﻼﻋ ﺯﺎﯿﻧ ﺩﺭﻮﻣ یﺎﻫﺭﺍﺰﺑﺍ
ﻮﺳﺭﺎﻬﭼ ﯽﺘﺷﻮﮔ ﭻﯿﭘ ﺭﺎﭼﺁ –
(10 mm, 8 mm, 6 mm) ﺖﺨﺗ ﺭﺎﭼﺁ –
ﻢﯿﻈﻨﺗ ﻞﺑﺎﻗ ﺖﺨﺗ ﺭﺎﭼﺁ –
