User’s Manual
Page 6
EN
3. You can copy the pictures, videos, and music from your PC to the internal
memory or delete the files on the internal memory.
Note: You can’t make any operation to the projector by the remote controller when
the projector is a USB device.
Projecting from External AV Source
AV IN
1. Follow the figure below to connect the external AV output device to the AV IN
jack on the rear panel of the unit. Connection is color-coded. After connection,
ensure that the corresponding (e.g.: Composite Video) mode is enabled in the
Input Source.
2. Enter “Source” in
main menu and
selete “AV mode”.
HDMI (Optional)
1. Use the HDMI cable to connect the HDMI port on the panel of the projector to
the external HDMI signal source. Ensure that the HDMI input is enabled in the
“Input Source” menu.
2. Enter “Source”
in main menu
and selete
“HDMI mode”.
VGA (Optional)
Use “Mini HDMI to VGA cable” to connect the HDMI port on the rear panel of the
projector to PC or other external source.
1. Plug one end of “Mini HDMI to VGA Cable” into the HDMI port on the projector.
2. Plug one end of “Mini HDMI to VGA Cable” into the VGA connector on PC or
other external source.
3. Enter “Source” in
main menu and
selete “PC mode”.
Note:
1. Supported screen resolution of PC:
‐ 1920 x 1080 / 1440 x 900 / 1400 x 1050
‐ 1360 x 768 / 1280 x 800 / 1280 x 768 / 1280 x 720
‐ 1152 x 864 / 1024 x 768 / 800 x 600
2. Many laptop computers do not automatically turn on their external video port
when a secondary display device such as a projector is connected. Refer to
your computer manual for the command that activates the external video port.
