OptiFlex® 3 Continuous Passive Motion (CPM) Therapy Unit

16

SETUP

PEDIATRIC FOOTPLATE SETUP

Pediatric Footplate

Remove footplate from unit. Lay aside for
re-installation.

Loosen the tibial adjustment knobs and
pull out the footplate assembly.

Rotate the footplate assembly 180° and
reinsert into the tibial adjustment tubes.
Tighten the tibial adjustment knobs.

Loosen the footplate adjustment knobs and
rotate footplate support as shown. Tighten
the footplate adjustment knobs.

Re-install footplate.

ACCESSORIES

Patient Kits
20533  OptiFlex Patient Kit
40128  34” Strap Kit

OptiFlex 3 CPM Unit Accessories
89900  OptiFlex Bedmount
89928 – OptiFlex Storage Rack
2031 – OptiFlex T Trolley
2032 – OptiFlex Lift
