OptiFlex® 3 Continuous Passive Motion (CPM) Therapy Unit

5

UNIT FAMILIARIZATION

NOMENCLATURE

Footplate Mounting Bracket

Footplate and Pendant Storage

Calf Support Assembly

Pendant

(See Page 6)

Transport and Storage

Handle

Motor Cover

Footplate Angle

Adjustment Knob

Footplate Angle

Adjustment Knob

Calf Length Adjustment

Knob (One on Each Side)

Unit Base Assembly

Thigh Adjustment Scale

Knob (One on Each Side)

Thigh

Adjustment Scale

(cm)

(One on Each

Side)

Knee Hinge

Knee Potentiometer

and Hinge

Femur Hinge

Assembly

(One on

Each Side)

Thigh

Support

Assembly
