Take the following precautions when inserting a new ribbon cassette.
Install the ribbon cassette so that the ribbon is between the print head and the
ribbon mask (see the figure on the left). Printing failure may occur if the ribbon is
placed behind the ribbon mask (see the figure below).
4 Precautions to take when replacing the ribbon
6 5
Replace the cover by fitting the tabs at
the bottom of the cover into the holes
located on the clock.
Then close the cover letting it snap
into place.
Turn the knob of the ribbon cassette in
the counter clockwise to tighten the
ribbon.
Print head
Ribbon mask
Ribbon
Print head
Ribbon mask
Ribbon
10
4
Correct Incorrect
