Acroprint DC7000 User Manual
Page 30
30
Electrical Connections
Parallel Port Connector on DC7000
Digital IO Mode
Printer Mode
1
Digital IO #7
1
Strobe
2
Digital IO #8
2
Printer Data 0
3
Digital IO #9
3
Printer Data 1
4
Digital IO #10
4
Printer Data 2
5
Digital IO #11
5
Printer Data 3
6
Digital IO #12
6
Printer Data 4
7
Digital IO #13
7
Printer Data 5
8
Digital IO #14
8
Printer Data 6
9
Digital IO #15
9
Printer Data 7
10 N/A
10 /ACK
11
Digital IO #2
11
Busy
12
Digital IO #3
12
PE
13
Digital IO #4
13
Slct
14 N/A
14 /Auto
Feed
15
Digital IO #5
15
/Error
16
Digital IO #6
16
/Init
17-25 Ground
17
/Slct
18-25
Ground
14 25
1 13
