11
Card Readers
The DC7000 is available with (3) types of card readers.
a) Magnetic stripe card reader. The magnetic stripe on the card
should be on the right side as shown in the illustration.
b) Internal barcode reader. Infrared or visible barcode readers are
available. The card is swiped through in the same fashion, but the
barcode should be on the left side of the card when swiped.
NOTE: For through-the-slot reading, the barcode should be located
on card as shown. Available barcode symbologies are 3 of 9
(Code 39) and 2 of 5 Interleaved.
Barcode Print Contrast Signal: 70% Min.
1.00” Min. Quiet Zones
0.35” Min.
.4”
Barcode Resolution: .01” (10mil) Min.
Wide to Narrow Ratio: 2.5 to 3.0
