6. Appendix

Units with Acroprint Data Collection Firmware

Acroprint Data Collection Terminal Setup Instructions

Configuring procedure for entering the DATE & TIME:

Swipe the Configuration Badge 000000000
(This badge is provided with each terminal)

Select option 1 for DATE

Select the Day, Month, Year DDMMYYYY

Select the Time HH:MM
(Time is entered in military time, 2:00 pm = 14:00)

Configuring procedure for selecting PORTS:

Swipe the Configuration Badge 000000000
(This badge is provided with each terminal.)

Select option 2 for Ports

Select option 0 for RS232

Select the baud rate 0 for 1200, 1 for 2400, 2 for 4800, 3 for 9600 and 4 for
19,200 baud.

(For modem terminal only)
Select option 1 for Modem

Select the Modem baud.

Select the Answer Window HHMMHHMM for starting and ending times

< press ENTER> (time is in military format, Example: Clock will not answer
during business hours and only answer between the hours of 8:00 pm and 6:00
am, then select 20000600.)
