(For RS485 terminals only)

Select option 1 for RS485

Select the baud rate 0 for 1200, 1 for 2400, 2 for 4800, 3 for 9600 and 4 for
19,200 baud.

(For Ethernet terminals only)

Select option 2 for Ethernet

Select the baud rate option 3 for 9600 baud
(Leave this as the default for Ethernet.)

Select the TCPIP address
(Your network administrator will have this information.)

Select the GATEWAY address
(Your network administrator will have this information.)

Select the PORT VALUE
(Default number 10001. Select the save value in the ATR9800 software.)

Select the NETMASK PART BITS NUMBER
(Your network administrator will obtain this information. The Default Subnet
Mask TCPIP number contains four groups of numbers separated by“.”. To
determine the NETMASK VALUE obtain your default Subnet IP number from
the Network administrator XXX.125.125.125 for your server Default Subnet,
convert each 125 (your numbers will be different) to binary and count the
number of zero’s in the binary number and enter this number. 125 = 01111101 in
binary. Each 125 has two zeros, therefore the Netmask bits number is set to 6.

Select the TERMINAL TRANSACTION PRINTER TYPE
(default is parallel port)

Select TRANSACTION TIME OUT
(This controls how long the terminal will restrict between badge swipes.
Example: You want to keep your employees off the terminal for at least 30
minutes for lunch, then set Transaction Time out to 30.)

Select TERMINAL ID
(default is 1, select the ID for terminal, each terminal MUST have a unique ID)

The terminal MUST be powered down and back up to accept the new TCPIP
information.
