PCH 3098
8 inch Atom Fanless Panel PC
© Copyright 2012 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com. 14628 Central Ave.
Chino, CA91710
Tel:909.597.7588, Fax:909.597.1939
Chapter 1 System
1.1 Specifications
Specs PCH 3098 PCH 3298 PCH3598
CPU Atom Z510p 1.1 GHz FSB 400 MHz, Z 530p 1.6 GHz FSB 533 MHz for option
Chipset US15WP
System Memory O n board 1 G B DDR2 400 MHz
Graphic Integrated Graphics GMA500
External I/O Port 2 x USB 2.0 ports
2 x RJ-45 LAN ports
1 x DB-9 RS-232
(CO M1) and RS-422/485
1 x DC power input
2 x USB 2.0 ports
2 x RJ-45 LAN ports
1 x DB-9 RS-232 (CO M1)
1 x DB-9, CO M2
(RS-232/422/485
connector, default
RS-232)
1 x DC power input
Standard I/O
2 x USB 2.0 ports
2 x RJ-45 LAN ports
1 x DB-9 RS-232 (COM1)
Connector
1 x DB-9, CO M2
(RS -232/422/485
connector, default
RS-232)
1 x DC power input
O ption
1 x VG A DB-15 port
1 x Audio Line-out port
Display Type 8 ” TFT-LCD 12 ” TFT-LCD 15 ” TFT-LCD
Max. Resolution 800 x 600 800 x 600 1024 x 768
Maximum Colors 262K 262K 16.2M
Viewing Angle (Degree) H:130/ V:110 H:140/V:110 H:160/V:130
