1 6. SA TA _P1 : (2.5mm Pitch 1x2 box Pin Header), an onboard 5V output connector is reserved to
provide power for SATA devices.
Pin# Signal Name
1 +DC5V
2 Ground
Note:
Output current of the connector must not be above 1A.
17 . SA TA 1/2:
(SATA 7P),SATA1,SATA2
SATA Connectors, Two SATA connectors are
provided, with transfer speed up to 3.0Gb/s.
18. JP2: (2.0mm Pitch 2x3 Pin Header), SATA1/SATA2/CF Devices Master or slave jumper setting.
SATA1/ SATA2/ CF devices can only be used two at the same time, and the Master device can be
set one only. While using SATA1/SATA2 devices at the same time, one of the devices must be
set as Master.
JP2 Devices Master
1~2 on
3~4 off
5~6 off
CF Master
1~2 off
3~4 on
5~6 off
SATA1 Master
1~2 off
3~4 off
5~6 on
SATA2 Master
