PCH 3098
8 inch Atom Fanless Panel PC
© Copyright 2012 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
14628 Central Ave.
Chino, CA91710
Tel:909.597.7588, Fax:909.597.1939
2
RXD (Received Data)
3
TXD (Transmit Data)
4
DTR (Data Terminal Ready)
5
Ground
6
DSR (Data Set Ready)
7
RTS (Request To Send)
8
CTS (Clear To Send)
9
JP3 Setting:
Pin1-2 : RI (Ring Indicator)
(default)
Pin3-4 : 5V Standby power
(option)
Pin5-6: 12V Standby power
(option)
9 . JP3:
(2.0mm Pitch 2x3 Pin Header), COM1 setting jumper, pin 1~6 are used to select signal out of
pin 9 of COM3 port.
JP3 Pin#
Function
Close 1-2
RI (Ring Indicator)
(default)
Close 3-4
COM1 Pin9=+5V
(option)
Close 5-6
COM1 Pin9=+12V
(option)
1 0. JP1:
(2.0mm Pitch 1x2 Pin Header), Backlight Control jumper setting for LVDS1.
Signal Name
JP1
PWM
Open
DC voltage Mode
Close
Note:
Please check first your LVDS panel backlight control by DC voltage Mode or PWM?
Panel backlight control by Level 5V.
