CHAPTER 2
HARDWARE INSTALLATION
The OPC8190 provides rich I/O ports and flexible expansions for you
to meet different demand, for example, CF card. The chapter will
show you how to install the hardware. It includes:
CompactFlash
™
Card
Serial Port
Ethernet
Mounting Method
Hard disk
DRAM
Wireless LAN Card
2.1 Open and close back cover
This section tells users how to open and close the back cover. Please
follow the steps below.
Step 1 Unscrew eleven screws on the back cover. Please
refer the photo of top side, right side and left side.
