1.4 I/O Outlets

Please refer to the following illustration for I/O locations of OPC8190.

No

Function

No

Function

1

POWER SWITCH (ATX)

7

COM 2 (RS-232)

2

Power Input connector (phoenix type)

8

VGA

3

2 X USB 2.0

9

1X ETHERNET (RJ-45)

4

COM 3 (RS-232)

10

2 X USB 2.0

5

COM 4 (RS-232)

11

AUDIO (LINE-OUT)

6

COM 1 (RS-232/422/485)
