11
ENGLISH
Camera
Touch Sensor ( ੬ pg. 6)
OK (DISP) Button [OK/DISP] ( ੬ pg. 13)
Menu Button [MENU]
Power Switch [POWER]
(You can turn off the camera by pressing
and holding this button.)
Speaker
Playback/Recording Mode Switching
Button [SELECT PLAY/REC] ( ੬ pg. 16)
Access/Charge Lamp [ACCESS/CHARGE]
(Blinks when you access fi les or charge
the battery. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Direct DVD Button [DIRECT DVD]
( ੬ pg. 22)/Title Button [TITLE]
Direct Backup Button [DIRECT BACK
UP] ( ੬ pg. 26)/Information Button [INFO]
( ੬ pg. 15)
Auto/Manual Mode Button [AUTO/
MANUAL]
Video Recording Start/Stop Button [START/
STOP] ( ੬ pg. 16)
Still Image Shooting Button [SNAPSHOT]
( ੬ pg. 17)
Zoom Lever [W , T ]
Speaker Volume Control [–VOL+]
(
੬ pg. 18)
Mode Switch [ , ]
DC Jack [DC] ( ੬ pg. 14)
Audio/Video Jack [AV]
USB (Universal Serial Bus) Jack [ ]
( ੬ pg. 22, 25 and 30)
LED Light
Camera Sensor
Remote Sensor ( ੬ pg. 15)
Lens Cover
Lens
Lens Cover Switch [
, ]
Stereo Microphone
microSD Card Slot
Stud Hole
Tripod Mounting Socket
Battery Release Button [BATT.] (
੬ pg. 14)
Battery Pack Mount ( ੬ pg. 14)
Grip Strap
Remote Control*
Infrared Beam Transmitting Window
ZOOM (T/W) Buttons
Zoom In/Out
Up Button
Rotate Button (counterclockwise)
(
੬ pg. 18)
Skip Backward Button
Left Button
Back Button
PLAYLIST Button
START/STOP Button
SNAPSHOT Button (
੬ pg. 17)
INFO Button ( ੬ pg. 15)
Skip Forward Button
PLAY/PAUSE Button
Right Button
Next Button
Down Button
Rotate Button (clockwise) ( ੬ pg. 18)
INDEX Button
DISP Button
* GZ-MG330 model does not include the remote
control.
