Effect Parameter List
Only the following parameter numbers are effective.
Parameter values consists of 2-bytes. Enter 00H for MSB and appropriate value for LSB.
* Parameter number 10 Dry/Wet is effective only when Variation connection is insertion.
TYPE Type Parameter Parameter Value Description
MSB(H) Number
01 HALL 1 Reverb Time 0-69 0.3~30.0s
02 ROOM 2 Diffusion 0-10
03 STAGE 3 Initial Delay 0-63 0.0~99.3ms
04 PLATE 4 HPF Cutoff 0-52 Thru~8.0kHz
5 LPF Cutoff 34-60 1.0k~Thru
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
11 Rev Delay 0-63 0.0~100.0ms
12 Density 0-4
13 Rev/Er Balance 1-127 RE
15 Feedback Level 1-127 -63~+63
05 DELAY L,C,R 1 Lch Delay 1-7200 0.1~720.0ms
2 Rch Delay 1-7200 0.1~720.0ms
3 Cch Delay 1-7200 0.1~720.0ms
4 Feedback Delay 1-7200 0.1~720.0ms
5 Feedback Level 1-127 -63~+63
6 Cch Level 0-127
7 High Damp 1-10 0.1~1.0
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
13 EQ Low Frequency 8-40 50Hz~2.0kHz
14 EQ Low Gain 52-76 -12~+12dB
15 EQ High Frequency 28-58 500Hz~16.0kHz
16 EQ High Gain 52-76 -12~+12dB
06 DELAY L,R 1 Lch Delay 1-7200 0.1~720.0ms
2 Rch Delay 1-7200 0.1~720.0ms
3 Feedback Delay 1 1-7200 0.1~720.0ms
4 Feedback Delay 2 1-7200 0.1~720.0ms
5 Feedback Level 1-127 -63~+63
6 High Damp 1-10 0.1~1.0
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
13 EQ Low Frequency 8-40 50Hz~2.0kHz
14 EQ Low Gain 52-76 -12~+12dB
15 EQ High Frequency 28-58 500Hz~16.0kHz
16 EQ High Gain 52-76 -12~+12dB
07 ECHO 1 Lch Delay1 1-3600 0.1~360.0ms
2 Lch Feedback Level 1-127 -63~+63
3 Rch Delay1 1-3600 0.1~360.0ms
4 Rch Feedback Level 1-127 -63~+63
5 High Damp 1-10 0.1~1.0
6 Lch Delay2 1-3600 0.1~360.0ms
7 Rch Delay2 1-3600 0.1~360.0ms
8 Delay2 Level 0-127
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
13 EQ Low Frequency 8-40 50Hz~2.0kHz
14 EQ Low Gain 52-76 -12~+12dB
15 EQ High Frequency 28-58 500Hz~16.0kHz
16 EQ High Gain 52-76 -12~+12dB
08 CROSS DELAY 1 L->R Delay 1-3600 0.1~360.0ms
2 R->L Delay 1-3600 0.1~360.0ms
3 Feedback Level 1-127 -63~+63
4 Input Select 0-2 L,R,L&R(L,R is mono mix)
5 High Damp 1-10 0.1~1.0
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
13 EQ Low Frequency 8-40 50Hz~2.0kHz
14 EQ Low Gain 52-76 -12~+12dB
15 EQ High Frequency 28-58 500Hz~16.0kHz
16 EQ High Gain 52-76 -12~+12dB
TYPE Type Parameter Parameter Value Description
MSB(H) Number
09 EARLY REF 1 Type 0-5 S-H, L-H, Rdm, Rvs, Plt, Spr
2 Room Size 0-127
3 Diffusion 0-10 0~10
4 Initial Delay 0-127 0.0~200.0ms
5 Feedback Level 1-127 -63~+63
6 HPF Cutoff 0-52 Thru~8.0kHz
7 LPF Cutoff 34-60 1.0k~Thru
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
11 Liveness 0-10
12 Density 0-3
13 High Damp 1-10 0.1~1.0
0A GATE REVERB 1 Type 0-1 TypeA, TypeB
0B REVERSE GATE 2 Room Size 0-127
3 Diffusion 0-10
4 Initial Delay 0-127 0.0~200.0ms
5 Feedback Level 1-127 -63~+63
6 HPF Cutoff 0-52 Thru~8.0kHz
7 LPF Cutoff 34-60 1.0k~Thru
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
11 Liveness 0-10
12 Density 0-3
13 High Damp 1-10 0.1~1.0
41 CHORUS 1 LFO Frequency 0-127 0.00~39.7Hz
42 CELESTE 2 LFO PM Depth 0-127
3 Feedback Level 1-127 -63~+63
4 Delay Offset 0-127 0.0~50.0ms
6 EQ Low Frequency 8-40 50Hz~2.0kHz
7 EQ Low Gain 52-76 -12~+12dB
8 EQ High Frequency 28-58 500Hz~16.0kHz
9 EQ High Gain 52-76 -12~+12dB
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
15 Input Mode 0-1 mono/stereo
43 FLANGER 1 LFO Frequency 0-127 0.00~39.7Hz
2 LFO Depth 0-127
3 Feedback Level 1-127 -63~+63
4 Delay Offset 0-127 0.0~50.0ms
6 EQ Low Frequency 8-40 50Hz~2.0kHz
7 EQ Low Gain 52-76 -12~+12dB
8 EQ High Frequency 28-58 500Hz~16.0kHz
9 EQ High Gain 52-76 -12~+12dB
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
14 LFO Phase Difference 4-124 -180 ° ~+180 ° (resolution 3 ° )
15 Input Mode 0-1 mono/stereo
44 SYMPHONIC 1 LFO Frequency 0-127 0.00~39.7Hz
2 LFO Depth 0-127
3 Delay Offset 0-127 0.0~50.0ms
6 EQ Low Frequency 8-40 50Hz~2.0kHz
7 EQ Low Gain 52-76 -12~+12dB
8 EQ High Frequency 28-58 500Hz~16.0kHz
9 EQ High Gain 52-76 -12~+12dB
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
45 ROTARY 1 LFO Frequency 0-127 0.00~39.7Hz
SPEAKER 2 LFO Depth 0-127
6 EQ Low Frequency 8-40 50Hz~2.0kHz
7 EQ Low Gain 52-76 -12~+12dB
8 EQ High Frequency 28-58 500Hz~16.0kHz
9 EQ High Gain 52-76 -12~+12dB
10* Dry/Wet 1-127 D63>W ~ D=W ~ D
