79
application, the port number can be a single
value, or a range (like 20-50). If you need to input
more than one port number and they’re not
contiguous, list all port numbers here and
separate them by comma ( , ). If the application
does not use TCP port, leave it blank.
UDP Port to Open) Input the UDP port number required by the
special application, the port number can be a
single value, or a range (like 20-50). If you need
to input more than one port number and they’re
not contiguous, list all port numbers here and
separate them by comma ( , ). If the application
does not use UDP port, leave it blank.
Comment You can input any text here to help you remember
the purpose of this item. This is optional.
Select Game This router comes with a numerous port mapping
settings of network games. If the game you wish
to set is listed here, you can select it from
dropdown menu.
After a game is selected, click ‘Add’ (the one next
to ‘Select Game’ dropdown list) to add the
connection parameters to all respective fields.
Add Click this button to add a new port mapping rule to
special applications table.
Reset Click this button to remove all values in every
field.
All existing special application mappings will be displayed in this page. To
delete one or more mappings, check the box of the mapping, then click
‘Delete Selected’ button to remove the mapping. To delete all existing
mappings, click ‘Delete All’ button. If you want to uncheck all boxes, click
‘Reset’.
