NSW-R4 WIRELESS BROADBAND ROUTER, 300M
Features
 Wireless 300M router with 4-port 10/100Mbps LAN switch and 802.11n access point
 Supports all IEEE802.11b/g/n WiFi standards
 Up to 300 Mbps data transfer rate via the wireless 802.11n protocol
 Built-in DHCP server automatically assigns and manages all IP addresses within your
LAN
 Advanced firewall, 64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security
 Supports Wi-Fi Protected Setup ( WPS ) with reset button
 Supports MAC/IP filtering and URL blocking (family filter)
 Easy to use Web-interface for all router management options
Specifications
 Supported standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE
802.3u, CSMA/CA,CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, PPTP
 Ports: - LAN: 4 x 10/100M Auto MDI/MDIX RJ45 ports
 WAN: 1 x 10/100M Auto MDI/MDIX RJ45 port
 Frequency band 2.4 ~ 2.4835GHz
 Channels: 1 ~ 11 (US, Canada), 1 ~ 13 (Europe)
 Supports Virtual Server and DMZ
 Supports DDNS (DynDNS, TZO) and QoS
 Data transfer rates: max 300 Mbps (11n), 54 Mbps (11g), 11 Mbps (11b)
 Encryption standards: WPS, WPA, WPA2, WPA2/WPA Mixed
 Antenna: 2 x 3 Dbi omni-directional antenna
 RF power: 20 dBm (max)
 Transmission distance: indoors up to 120 m, outdoors up to 360 m (distance is
dependent of environmental conditions, obstructions, walls, ceilings, etc)
 Dimensions: 153 x 100 x 30 mm (W x D x H)
 Operating temperature: 0 ~ 40 °C
 Storage temperature: -40 ~ 70 °C
 Operating humidity: 10 ~ 90 % non-condensing;

Storage humidity: 5 ~ 95 % non-condensing
