Clamp the machine in this position by tighten-
ing the rotary knob [5.1].

Press the depth stop [5.3] against one of the

three fi xed stops on the rotary stepped stop
[5.4].

Slide the indicator [5.5] down to the 0 mm mark

on the scale [5.7].

If the base position of the indicator is incor-
rect, this can be adjusted by turning the screw
[5.6] on the indicator.

The stepped stop [Fig. 7] has three stops, two of
which can be adjusted in height using a screw-
driver:

Stop

Height

A

18 mm - 51 mm

B

6 mm - 18 mm

C

0 mm

Stop C has an offset for preliminary routing -
see "Preliminary/Fine routing".

b) Presetting the routing depth

Pull the depth stop [6.6] upwards until the indi-

cator [6.2] reaches the required routing depth.

Clamp the depth stop in this position using the

clamp lever [6.3].

Unscrew the rotary knob [6.1]. The machine is

now in starting position.

If necessary, you can readjust the routing depth

by turning the adjusting wheel [6.8]. Each mark
represents a routing depth of 0.1 mm. One com-
plete turn of the wheel is 1 mm.

The dial ring [6.7] can be turned separately to
the "zero" setting.

The three marks [6.4] indicate the maximum
adjustment range of the adjusting wheel
(20 mm) and the central position when aligned
with the edge [6.5].

7.5 Preliminary/Fine routing

Stop C has two stop limits with a height difference
of 2 mm. Routing to the depth preset with stop C
can be performed in two steps:

Lower the router to the fi rst stop level [7.1] for

the preliminary routing step;

Lower the router to the second stop level [7.2]

to complete the routing procedure.

This procedure enables rapid routing to a con-
siderable depth while still achieving a good

surface quality. The fi nal routing depth is de-
fi ned by adjusting the stop level [7.2].

7.6 Fine adjuster for edge trimming

The machine has a special fi ne adjuster for rout-
ing tools with a bearing guide, which allows quick
and easy precision adjustment prior to rounding
edges and prevents offsets [Fig. 8].

First of all, roughly preset the routing depth and
perform a test run.

Then adjust the routing depth more precisely:

Open the clamping lever [9.2].

Push the depth stop [9.3] against the fi xed stop

C [9.5].

Clamp the depth stop using the eccenter [9.4] on

the stepped stop (turn clockwise).

Close the clamping lever [9.2].

Unscrew the rotary knob [9.1].

Turn the adjusting wheel [9.6] to set the routing

depth more precisely.

The routing depth can be adjusted in both di-
rections because the depth stop is connected
to the stepped stop.

Tighten the rotary knob [9.1].

Open the eccenter [9.4] (turn anticlockwise).

Perform more test runs and make the appro-

priate adjustments if necessary.

7.7 Dust extraction

CAUTION

Breathing in dust can damage the respiratory
passage.

Always connect the machine to a dust extractor.

Only work with the chip guard [10.2] in perfect

working order.

When performing work that generates dust,

always wear a dust mask.

A Festool dust extractor with an extractor hose
diameter of 36 mm or 27 mm (36 mm recom-
mended due to the reduced risk of clogging) can
be connected to the extractor connector [10.4]

The extractor connector [10.4] can be rotated
within the range indicated [10.3]. The extractor
connector on the extraction pipe will no longer be
secure if rotated outside of this range.
