Product specification and feature
2-24
◆ AC Input
Input Rated Voltage AC 220V ~ 240V AC 110V ~ 127V
Input Voltage fluctuating range AC 198V ~ 264V AC 99V ~ 135V
Rated Frequency 50/60 Hz
Frequency Fluctuating range 47 ~ 63 Hz
Input Current
Under 4.0Arms / 2.0Arms (But, the status when e-coil is off or
rated voltage is inputted/outputted )
◆ Rated Output Power
NO ITEM CH1 CH2 Remark
1 CHANNEL NAME +5.0V +24.0V
2 CONNECTOR PIN
CON 3
5V PIN : 11,13,15
GND PIN : 12,14,16 CON 3
24V PIN : 3,5,7,9
GND PIN : 4,6,8,10
3 Rated Output
+5.1V ± 5%
(4.845 ~ 5.355V) +24V ± 10%
(21.6 ~ 26.4V)
4 Max. Output Current 2.0 A 2.5 A
5 Peak Loading Current 2.4 A 2.7 A 1ms
6 RIPPLE NOISE Voltage Under 100mVp-p Under 500mVp-p
7 Maximum output 10W 60W
8 Peak output 12W 64.8W 1ms
9
Protection for loading
shortage and overflowing
current
Shut down or Fuse
Protection Shut down or Output
Voltage Drop
• Supply
- Output Voltage : - 400 V ~ - 800V DC ±50 V(ZENER using, DEV )
- Input contrast of the output stability degree : under ± 5 %
Loading contrast : ± 5 % or less
- Output Voltage Rising Time : 50 ms Max
- Output Voltage Falling Time : 50 ms Max
- Output Loading range : 10 MΩ ~ 1000 MΩ
- Output Control Signal (BIAS- PWM) : the CPU is HV output when PWM is low.
■ SMPS Board
