Powering Up the Router 23
Mounting
Instructions for
Wood Walls
To wall mount the unit:
1 Make two holes 98 mm (3.9 in.) apart.
2 Fix two suitable screws directly into the wall, leaving their heads 3 mm
(0.12 in.) clear of the wall surface. The screws should be at least 20 mm
(0.75 in.) long.
3 Remove any connections in the Router and locate it over the screw heads.
When in line, gently push the Router on to the wall and move it
downwards to secure.
CAUTION: When making connections, be careful not to push the unit up
and off the wall.
Powering Up the
Router To power up the Router:
1 Plug the power adapter into the power adapter socket located on the
back panel of the Router.
2 Plug the power adapter into a standard electrical wall socket.
Connecting the
Router The first step for installing your Router is to physically connect it to the
telephone socket and then connect it to a computer in order to be able to
access the Internet. See
Figure 6 and Figure 7 :
