99-00962-20 REV C0
7 9 | S M A R T M O B I L E S T A N D R U N N I N G D I A G R A M S
Cable Descriptions
• Used on This Model
NA North American
Model
INT International Model
IO Required for
Interactive Overlays
Cable From To Description Length
SMART
Part No.
NA
(100)
INT
(100)
NA
(100H)
INT
(100H)
Audio/Video
AV01 Computer Flat-Panel
Display
VGA Male + 3.5 mm Male
to VGA Male + 3.5 mm Male
10' (3 m) 93-00683-20 • •
AV02 Device Two,
e.g., VCR
Flat-Panel
Display /
SMART Hub
SE240
Three-Plug RCA Male
to Three-Plug RCA Male
8' (2.4 m) 93-00685-20 • • • •
AV03 Device One,
e.g., DVD /
Blu-ray
Player
Flat-Panel
Display
Five-Plug RCA Male
to Five-Plug RCA Male
8' (2.4 m) 93-00684-20 • •
AV04 Laptop Connection
Panel
VGA Male + 3.5 mm Male
to VGA Male + 3.5 mm Male
6' (1.8 m) 93-00699-20 • • • •
AV05 Computer SMART Hub
SE240 / AD08
VGA Male + 3.5 mm Male
to VGA Male + 3.5 mm Male
6' (1.8 m) 93-00699-20 • •
Audio
A01 Connection
Panel
Flat-Panel
Display /
SMART Hub
SE240
3.5 mm Stereo Female
Chassis to 3.5 mm Male
6' (1.8 m) 93-00681-20 • • • •
A02 Flat-Panel
Display
Speaker 16 AWG Speaker Cable 8 1/2'
(2.6 m)
93-00686-20 • • • •
A03 Flat-Panel
Display
Speaker 16 AWG Speaker Cable 8 1/2'
(2.6 m)
93-00689-20 • • • •
A04 SMART Hub
SE240
Flat-Panel
Display
Two-Plug RCA Male
to 3.5 mm Male
6' (1.8 m) 93-00513-20 • •
A05 Device One,
e.g., DVD/
Blu-ray
Player
SMART Hub
SE240
Two-Plug RCA Male
to Two-Plug RCA Male
6' (1.8 m) 93-00139-20 • •
