M O D E L F S S B I D 1 0 0 : C O N N E C T I N G D E V I C E S I N S I D E Y O U R S M A R T M O B I L E
S T A N D ’ S C A B I N E T
To connect your
flat-panel display
1.
Connect speaker cables A02 and A03 to your flat-panel display’s
speaker receptacles.
2.
Connect the VGA video plug from cable AV01 to your flat-panel display’s VGA
video receptacle.
NOTE
If your flat-panel display has more than one VGA video receptacle, use
the receptacle adjacent or closest to a 3.5 mm audio receptacle.
3.
Connect the 3.5 mm stereo audio plug from cable AV01 to an audio receptacle
on your flat-panel display’s connection panel. Typically, this audio receptacle
is beside the VGA connection.
4.
Connect the 3.5 mm stereo audio plug from cable A01 to a second audio
receptacle on your flat-panel display’s connection panel.
NOTE
If your flat-panel display’s connection panel has only one 3.5 mm audio
receptacle, contact your
purchase
a 3.5 mm audio Y-adapter cable.
5.
Connect cable V01 as follows:
–
Connect the red BNC plug to the red BNC receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled R.
–
Connect the green BNC plug to the green BNC receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled G.
–
Connect the blue BNC plug to the blue BNC receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled B.
–
Connect the white BNC plug to the white BNC receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled H.
–
Connect the yellow BNC plug to the yellow BNC receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled V.
6.
Connect cable AV02 as follows:
–
Connect the yellow plug to the yellow RCA receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled V or VIDEO.
–
Connect the red plug to the adjacent red RCA receptacle on your flat-panel
display’s connection panel. This receptacle is typically labeled R.
–
Connect the white plug to the adjacent white RCA receptacle on your
flat-panel display’s connection panel. This receptacle is typically labeled L.
