TECHNICAL DATA
50 XEROX WIDE FORMAT 510dp OPERATOR MANUAL
The XEROX Wide Format 510dp will operate within the
specifications indicated in the table below for the respective
markets. Current limit will be set as part of the installation
procedure. The printer is not sensitive to the AC power service
frequency and can operate at either 50hz or 60hz.
Table 6. Operating Power
Market area AC power service
rating
Maximum current
consumption
First Print Out Time
US/Canada 208V – 240V @ 20A
208V – 240V @ 15A 17.6A
13.2A Less than 3 minutes
Less than 4 minutes
European Operations -
Common Market 230V – 240V @ 16A 16.0A Less than 3 minutes
United Kingdom 230V – 240V @ 13A 13.0A Less than 3.5 minutes
Switzerland 220V @ 10A 10.0A Less than 5 minutes*
Central/South America 220V – 240V @ 20A 15A Less than 3 minutes
The table below shows maximum print throughput in prints per
minute. It assumes continuous printing from a single roll with no
AC power limitation.
Table 7. Maximum Prints Per Minute
US Europe/Central and South America
Portrait Landscape Portrait Landscape
N/A A = 23 N/A A4 = 24
B = 13 B = 18 A3 = 13 A3 = 18
C = 10 C = 13 A2 = 10 A2 = 13
D = 7 D = 10 A1 = 7 A1 = 10
E = 5 N/A A0 = 5 N/A
