TABLE 5: COOLING CAPACITY 26.4 KW UNIT - METRIC
Air On
Evap. Coil
Temperature of Air on Condenser Coil 29°C Temperature of Air on Condenser Coil 35°C
m 3 /s
WB
(°C)
Tot.
Cap.
1
(kW)
Tot.
Input
2
(kW)
Sensible Capacity (kW) 1
Return Dry Bulb (°F)
Tot.
Cap.
1
(kW)
Tot.
Input
2
(kW)
Sensible Capacity (kW) 1
Return Dry Bulb (°C)
30 28 27 25 23 22 20 30 28 27 25 23 22 20
1.06
22 31 8.6 18 16 14 12 10 - - 29 9.2 17 15 13 11 9 - -
19 28 8.4 22 20 18 16 14 12 10 26 9.0 21 19 17 15 13 11 9
17 26 8.2 26 24 22 20 18 16 14 24 8.6 24 22 20 18 16 15 13
14 25 8.2 25 24 23 21 19 17 15 23 8.6 23 23 21 19 17 15 13
1.24
22 31 8.7 19 17 15 13 10 - - 30 9.3 18 16 14 12 9 - -
19 29 8.5 24 22 19 17 15 13 10 27 9.1 23 21 18 16 14 12 10
17 27 8.3 26 26 24 21 19 17 15 24 8.7 24 24 22 20 18 15 13
14 25 8.2 25 25 24 22 20 18 15 24 8.7 24 23 23 20 18 16 14
1.42
22 32 8.8 21 19 16 13 11 - - 31 9.4 20 18 15 13 10 - -
19 30 8.6 26 23 21 18 16 13 10 28 9.2 25 23 20 17 15 12 10
17 27 8.3 27 27 25 23 20 18 15 25 8.8 25 25 24 21 19 16 14
14 26 8.3 26 26 26 24 21 18 16 24 8.8 24 24 24 22 19 17 14
1.59
22 33 8.8 23 20 17 14 11 - - 31 9.4 22 19 16 13 10 - -
19 30 8.6 28 25 22 19 16 13 10 28 9.2 27 24 21 18 15 12 9
17 28 8.4 28 28 27 24 21 18 15 25 8.9 25 25 25 22 19 16 13
14 27 8.3 27 27 27 24 21 18 15 25 8.9 25 25 25 22 19 16 13
1.77
22 34 8.9 24 21 18 14 11 - - 32 9.5 23 20 17 13 10 - -
19 31 8.7 29 26 23 20 16 13 10 29 9.3 29 25 22 19 15 12 9
17 28 8.4 28 28 28 25 21 18 15 26 8.9 26 26 26 23 19 16 13
14 27 8.4 27 27 27 24 21 17 14 25 8.9 25 25 25 22 19 15 12
Temperature of Air on Condenser Coil 41°C Temperature of Air on Condenser Coil 46°C
1.06
22 27 9.8 16 14 12 10 8 - - 25 10.4 15 13 11 9 8 - -
19 24 9.5 20 18 16 14 12 10 8 21 10.0 19 17 15 13 11 9 7
17 21 9.1 21 21 19 17 15 13 11 19 9.7 19 19 17 15 14 12 10
14 21 9.1 21 21 19 17 15 13 11 19 9.7 19 19 17 15 13 11 10
1.24
22 28 9.9 18 15 13 11 9 - - 25 10.5 17 15 12 10 8 - -
19 25 9.6 22 20 17 15 13 11 8 22 10.1 21 19 16 14 12 10 7
17 22 9.3 22 22 20 18 16 14 12 20 9.8 20 20 19 17 14 12 10
14 22 9.3 22 22 21 18 16 14 12 20 9.8 20 20 19 16 14 12 10
1.42
22 28 10.0 19 17 14 12 9 - - 26 10.6 19 16 13 11 8 - -
19 25 9.7 24 21 19 16 14 11 9 23 10.2 23 20 18 15 13 10 7
17 23 9.4 23 23 22 20 17 14 12 21 9.9 21 21 21 18 15 13 10
14 22 9.4 22 22 22 20 17 15 12 20 9.9 20 20 20 18 15 12 10
1.59
22 29 10.1 21 18 15 12 9 - - 27 10.7 20 17 14 11 8 - -
19 26 9.8 25 23 20 17 14 11 8 23 10.3 23 22 19 16 13 10 7
17 23 9.4 23 23 23 20 17 14 11 21 10.0 21 21 21 18 15 12 9
14 23 9.4 23 23 23 20 17 14 11 21 10.0 21 21 21 18 15 12 9
1.77
22 29 10.1 22 19 16 13 9 - - 27 10.8 21 18 15 12 8 - -
19 26 9.8 26 24 21 18 14 11 8 24 10.4 24 23 20 16 13 10 7
17 24 9.5 24 24 24 20 17 14 11 21 10.1 21 21 21 18 15 12 8
14 23 9.5 23 23 23 20 17 13 10 21 10.1 21 21 21 18 14 11 8
Temperature of Air on Condenser Coil 52°C
1.06
22 23 11.0 14 12 11 9 7 - -
19 19 10.5 18 16 14 12 10 8 6
17 17 10.2 17 17 16 14 12 10 8
14 17 10.2 17 17 15 13 12 10 8
1.24
22 23 11.1 16 14 12 9 7 - -
19 20 10.6 20 17 15 13 11 9 6
17 18 10.3 18 18 17 15 13 11 9
14 18 10.3 18 18 17 14 12 10 8
1.42
22 24 11.2 18 15 13 10 7 - -
19 20 10.8 20 19 17 14 11 9 6
17 18 10.4 18 18 18 16 14 11 9
14 18 10.5 18 18 18 16 13 10 8
1.59
22 25 11.4 19 16 13 10 7 - -
19 21 10.9 21 20 18 15 12 9 6
17 19 10.5 19 19 19 16 13 10 7
14 19 10.6 19 19 19 16 13 10 7
1.77
22 25 11.5 21 17 14 11 8 - -
19 21 11.0 21 21 19 15 12 9 5
17 19 10.6 19 19 19 16 12 9 6
14 19 10.7 19 19 19 16 12 9 6
1 These capacities are gross ratings. For net
capacity, deduct air blower motor. Refer to the
appropriate Blower Performance Table for the
kW of the supply air blower motor.
2 These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
