Overview
Front Panel
14 Operating Manual for XDC Series Slave Power Supply
Front Panel
Figure 1.1 Slave Front Panel
1. Rack mount brackets
2. Handles
3. ON/OFF Switch
4. Power On status LED (green)
5. Ouput Off status LED (red) Lit when the output is disabled
6. Front panel display (vacuum fluorescent display)
