Prestige 660R-6xC Series User’s Guide
Chapter 21 Network Address Translation (NAT) 172
Figure 112 Example 4: Menu 15.1.1.1 Address Mapping Rule
After you’ve configured your rule, you should be able to check the settings in menu 15.1.1 as
shown next.
Figure 113 Example 4: Menu 15.1.1 Address Mapping Rules
Menu 15.1.1.1 Address Mapping Rule
Type= Many-to-Many No Overload
Local IP:
Start= 192.168.1.10
End = 192.168.1.12
Global IP:
Start= 10.132.50.1
End = 10.132.50.3
Server Mapping Set= N/A
Press ENTER to Confirm or ESC to Cancel:
Menu 15.1.1 - Address Mapping Rules
Set Name= Example4
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- -------------- --------------- ------------- ---
1. 192.168.1.10 192.168.1.12 10.132.50.1 10.132.50.3 M:M NO OV
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
