Prestige 660R-6xC Series User’s Guide

Chapter 18 Remote Node Configuration

146

18.4.2 Web Configurator Filter Sets

When you apply filter rules using the web configurator, filter sets 11 and 12 are automatically
generated in SMT menu 21. This feature is not available on all models.

Figure 78 Menu 21 Filer Set Configuration

The following figures display the filter rules in filter sets 11 and 12.

Menu 21 - Filter Set Configuration

Filter Filter
Set # Comments Set # Comments
------ ----------------- ------ -----------------
1 _______________ 7 _______________
2 NetBIOS_WAN 8 _______________
3 NetBIOS_LAN 9 _______________
4 _______________ 10 _______________
5 _______________ 11 WebSet1
6 _______________ 12 WebSet2

Enter Filter Set Number to Configure= 0
