Prestige 660R-6xC Series User’s Guide
145 Chapter 18 Remote Node Configuration
Figure 76 Menu 11.5 Remote Node Filter (PPPoA or PPPoE Encapsulation)
18.4.1 Web Configurator Internet Security Filter Rules
In the web configurator, open the Security screen as shown next. Select the predefined filter
rules and click Apply.
Figure 77 Internet Security
Once you apply the filter rules in the web configurator, filter sets 11 and 12 are automatically
applied in the protocol filters field under Input Filter Sets in SMT menu 11.5.
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters= 1, 5, 9, 12
device filters=
Output Filter Sets:
protocol filters=
device filters=
Call Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
Note: SMT input protocol filter set numbers that were
previously applied are erased after you apply the Internet
Security filter rules in the web configurator. To reapply them or
apply new filter sets, you need to enter the filter set numbers
again along with filter sets 11 and 12. For example, to apply
filter sets 1 and 2, you enter "1, 2, 11, 12".
