Prestige 128MH PSTN Router/Hub
1-6
Getting to Know Your Router/Hub
1.4.2 Front Panel LEDS
The LED indicator lights on the front panel of your Prestige indicate the router/hub functional
status. The following Table 1-1 describes the LED functions:
Table 1-1.
LED Functions
LEDs
Function
Indicator
Status
Active
Description
PWR
Power Indicator Green
On
The Prestige is powered on.
RUN
Running status
indicator
Green
Blinking
The Prestige is functioning properly.
Ready
Green
On
The modem or IDSN TA connected to WAN port is
ready for service.
WAN
Transmit/Receive Green
Blinking
Traffic is being transmitted or received on WAN port.
On
An active station is connected to the port.
ETHER-
NET
1,2,3,4 LAN Transmit
LAN Receive
Green
Blinking
The connected station is transmitting.
RDY
Ready
Green
On
The modem is ready for service.
MODEM-
1,2
TX/RX
Transmit/Receive Green
Blinking
Traffic is being transmitted or received on the modem.
