Prestige 128MH PSTN Router/Hub
13-2 System Maintenance
13.1 System Status
The first selection, System Status, gives you information on the version of your system firmware
and the status and statistics of the ports, as shown in Figure 13-2.
Figure 13-2. Menu 24.1 - System Maintenance - Status
Follow the procedure below to go to the System Status Menu.
Step 1. Select option 24 from the Main Menu to access Menu 24 - System Maintenance.
Step 2. From Menu 24, select option [1. System Status].
Step 3. There are five possible commands in Menu 24.1 - System Maintenance - Status.
l Entering 1 or 2 or 3 to disconnect the call on the specified WAN port;
l Entering 8 to disconnect the calls on all WAN ports,
l Entering 9 to reset the counters, and [Esc] to exit this screen.
Please note that entering 9 will reset all counters except the Total Outcall Time.
Menu 24.1 -- System Maintenance - Status
Port
M1
M2
WAN
Status
Idle
Idle
Down
Speed
0Kbps
0Kbps
0Kbps
TXPkts
0
0
0
RXPkts
0
0
0
Errs
0
0
0
Tx B/s
-
-
-
Rx B/s
-
-
-
Up Time
0:0
0:0
0:0
Tota l Outcall Time: 0:00:00
Ethernet:
Status: 10M/Full Duplex
TX Pkts: 26
RX Pkts: 0
Collisions: 0
Name: p128MH
RAS S/W Version: V1.6(e01) | 2/6/98
Ethernet Address: 00:a0:c5:01:23:45
LAN Packet Which Triggered Last Call:
Press Command:
CMDS: 1 -Drop M1 2-Drop M2 3-Drop WAN port 8-Drop All 9-Rst Cnt ESC-Exit
