Scenario 2 – Load Sharing
Furthermore, ZyCompany wants to achieve load sharing based on the
high availability application. To reach this target, two VRRP groups would be
recommended. Each switch is a Master of one VRRP group and also acts a
Backup of another VRRP group.
Network Admin will need to separate LAN users to two groups, each one
use one virtual IP to share LAN traffic loading. So if the both Master are alive,
PC group1’s traffic will mainly go via SwitchA while PC group2’s will mainly go
via SwitchB. See following topology and configuration step by step.
