ZyXEL Communications ZyXEL Dimension ES-4124 User Manual
Page 61
ES-4124 Support Notes
All contents copyright (c) 2006 ZyXEL Communications Corporation.
61
Step 4: In the ES-3124, after the MVR configuration, click the Advanced
Application to browse the VLAN Status and see we have add a new VLAN
100 in the VLAN list. We also create three separate VLANs, 20, 30, 40 and
assign their PVID as 20, 30 and 40 respectively.
Figure 7 VLAN Status
