Basic Installation Procedures

975-0468-01-01

1–29

This guide for use by qualified installers only

Testing in Shore Power Mode

To test the Freedom HW in shore power mode:
◆ With the appliance from the previous test still connected and

operating, connect the shore power source.

The Freedom HW transfers the appliances to shore power. The status
LED on the display panel will change from yellow to a ten-second
flashing yellow and then green.

If the appliance operates, your installation is successful.

Note:

If the Inverter button on the Freedom HW is set to Standby, the Freedom

HW will automatically supply the appliances with inverter power if the shore
power source fails or becomes disconnected or the shore power voltage is too low
(less than 95 volts AC).

WARNING: Shock hazard

Whether or not the Inverter button is turned ON, shore power will pass through
the Freedom HW to the output when shore power is within normal operating
range.
