Step 2: Choosing a Location for the Freedom HW
The Freedom HW should only be installed in locations that meet the
following requirements:
❐ Dry. Do not allow water or other fluids to drip or splash on the
Freedom HW. Do not mount the Freedom HW in an area subject
to splashing water or bilge water.
❐ Cool. Normal air temperature should be between 21 °F and 165 °F
(–20 °C and 60 °C)—the cooler the better.
❐ Ventilated. Allow at least 5 in. (13cm) of clearance at the DC end of
the Freedom HW for air flow, 1 in. (2.5cm) on each side, and 2 in.
(5cm) at the AC end. The more clearance for ventilation around the
unit, the better the performance. Do not allow the ventilation
openings on the ends of the unit to become obstructed.
❐ Safe. Do not install the Freedom HW in the same compartment as
batteries or in any compartment capable of storing flammable liquids
like gasoline.
❐ Close to the battery compartment and the AC source and load
panels. Avoid excessive cable lengths (which reduce input and output
power due to wire resistance). Use the recommended cable lengths
and sizes, especially between the battery banks and the Freedom HW.
❐ Protected from battery acid and gases. Never allow battery acid to
drip on the Freedom HW or its wiring when reading specific gravity
or filling the battery. Also do not mount the unit where it will be
exposed to gases produced by the batteries. These gases are very
corrosive, and prolonged exposure will damage the Freedom HW.
WARNING: Fire and explosion hazard
This equipment contains components that tend to produce arcs or sparks. To
prevent fire or explosion, do not install the Freedom HW in compartments
containing batteries or flammable materials, or in locations that require ignition-
protected equipment. This includes any space containing gasoline-powered
machinery, fuel tanks, or joints, fittings, or other connections between
components of the fuel system.
WARNING: Fire hazard
To reduce the risk of fire, do not cover or obstruct the ventilation openings. Do
not install the Freedom HW in a zero-clearance compartment. Overheating may
result.
