33 MIDI Functions
■
MIDI Clock Select
This function determines whether the Clavinova’s rhythm and ABC timing is controlled by the Clavinova’s own in-
ternal clock or an external MIDI clock signal received from external equipment connected to the MIDI IN connector.
The Clock Mode is automatically set to INTERNAL when the power is initially turned on.
Z
Hold [MIDI/TRANSPOSE] and press the [ORGAN].
X
Release [MIDI/TRANSPOSE].
NOTES
• If the Clock Mode is set to EXTERNAL and a MIDI clock signal is not being received
from an external source, the rhythm, ABC and other clock-dependent features will not
operate.
■
MIDI Transpose Transmit
This function transposes the pitch of transmitted MIDI note data up or down in semitone intervals up to a maximum
of six semitones. The pitch of notes played on the keyboard is not affected.
Z
Hold [MIDI/TRANSPOSE] and press [UPRIGHT BASS].
X
Use the TEMPO [▲] and [▼] buttons to select the desired degree of transposition
while holding the [MIDI/TRANSPOSE] button.
The amount of transposition selected is shown on the TEMPO display.
C
Release [MIDI/TRANSPOSE].
NOTES
• Press the TEMPO [ ▲ ] and [ ▼ ] buttons simultaneously while holding the [MIDI/
TRANSPOSE] button to restore normal transmitted pitch.
• Transpose is always set to Normal when the power is turned on.
This function causes all the current Clavinova panel settings (selected voice, etc) to be transmitted via the MIDI OUT
connector. This is particularly useful if you will be recording performances to a MIDI sequence recorder which will be
used to control the Clavinova on playback. By transmitting the Clavinova panel settings and recording them on the MIDI
sequence recorder prior to the actual performance data, the Clavinova will be automatically restored to the same settings
when the performance is played back.
Z
Hold [MIDI/TRANSPOSE] and press [CHOIR].
X
Release [MIDI/TRANSPOSE].
■
Panel Data Send
Display Transposition
t-6 -6 semitones
t-5 -5 semitones
t-4 -4 semitones
t-3 -3 semitones
t-2 -2 semitones
t-1 -1 semitone
t - 0 Normal
t - 1 +1 semitone
t - 2 +2 semitones
t - 3 +3 semitones
t - 4 +4 semitones
t - 5 +5 semitones
t - 6 +6 semitones
Z
Hold [MIDI/TRANSPOSE] and press [ELEC BASS].
X
Release [MIDI/TRANSPOSE].
NOTES
• The panel voices you play on the keyboard are not converted to the Clavinova Com-
mon Voices in this mode.
■
The Clavinova Common Voice Mode
This mode is similar to the Multi-Timbre Mode described on page 32, but MIDI program change numbers received
on all channels are converted to Yamaha Clavinova Common Voice Numbers. MIDI program change numbers transmit-
ted when the panel voice selectors are operated are also converted to the common voice numbers.
The Clavinova Common Voice mode is always off when the power is initially turned on. It can be activated as fol-
lows:
= Common Voice mode
ON.
= Common Voice mode
OFF.
ELEC
BASS
ELEC
BASS
= EXTERNAL.
= INTERNAL.
ORGAN
ORGAN
