32
MIDI Functions
■
The Multi-Timbre Mode
The Multi-Timbre mode is a special mode in which the Clavinova voices can be independently controlled on differ-
ent MIDI channel numbers (1 through 15) by an external MIDI device. The Multi-Timbre mode is off when the power is
initially turned on.
The Multi-Timbre mode can be activated as follows:
Z
Hold [MIDI/TRANSPOSE] and press [GUITAR].
X
Release [MIDI/TRANSPOSE].
In this mode MIDI program change numbers received by the Clavinova select
the corresponding Clavinova voices — i.e. the same voices selected by the panel
controls. The Clavinova Common Voice Mode described on page 33 also allows
multi-timbre control of the Clavinova, but with different voice assignments.
● Rhythm Instrument Note Assignments
The Clavinova’s rhythm instruments are controlled via MIDI channel 15. The note assignments for the various rhythm
instruments are given below:
■
The Split Send Mode
In the split send mode notes played on the left-hand section of the keyboard (to the left of and including the split
point key — see “Changing the Split Point” on page 10) are transmitted on MIDI channel 2, while the upper keyboard
section transmits on the MIDI channel set using the Send Channel Select function described earlier. In this mode the
left- and right-hand sections of the keyboard can be used to play separate external keyboards or tone generators set to
receive on the appropriate channels. The Split Send Mode is automatically turned off when the power is initially turned
on.
Z
Hold [MIDI/TRANSPOSE] and press [STRINGS].
X
Release [MIDI/TRANSPOSE].
= Split Send Mode ON.
= Split Send Mode OFF.
STRINGS
STRINGS
= Multi-Timbre mode ON.
= Multi-Timbre mode OFF.
GUITAR
GUITAR
MIDI
Note
Note No.
Instrument
A1 45 (CYMBAL DAMP)
F # 2 54 BRUSH ROLL
G # 2 56 HI-HAT CLOSED HEAVY
A # 2 58 CRASH CYMBAL LIGHT
B2 59 BASS DRUM LIGHT
C3 60 SNARE DRUM + RIM HEAVY
C # 3 61 RIDE CYMBAL CUP
D3 62 SNARE DRUM + RIM LIGHT
F3 65 BASS DRUM NORMAL
F # 3 66 RIM SHOT
G3 67 SNARE DRUM HEAVY
G # 3 68 BRUSH SHOT
A3 69 SNARE DRUM LIGHT
A # 3 70 HI-HAT PEDAL
B3 71 SNARE DRUM ECHO
C4 72 TOM 4
C # 4 73 HI-HAT CLOSED NORMAL
MIDI
Note
Note No.
Instrument
D4 74 TOM 3
D # 4 75 HI-HAT OPEN
E4 76 TOM 2
F4 77 TOM 1
F # 4 78 RIDE CYMBAL NORMAL
G4 79 ELECTRIC TOM 3
G # 4 80 CRASH CYMBAL NORMAL
A4 81 ELECTRIC TOM 2
A # 4 82 CRASH CYMBAL
B4 83 ELECTRIC TOM 1
C5 84 CONGA LOW
C # 5 85 CABASA
D5 86 CONGA HIGH
D # 5 87 METRONOME
E5 88 BONGO HIGH
F5 89 TIMBALE LOW
MIDI
Note
Note No.
Instrument
F # 5 90 CLAVES
G5 91 TIMBALE HIGH
G # 5 92 CASTANETS
A5 93 CUICA LOW
A # 5 94 COWBELL
B5 95 CUICA HIGH
C6 96 HAND CLAP
C # 6 97 AGOGO LOW
D # 6 99 AGOGO HIGH
E6 100 BONGO LOW
F6 101 (CUICA LOW)
F # 6 102 (TAMBOURINE)
G6 103 (CRASH CYMBAL)
G # 6 104 (TRIANGLE CLOSED)
A6 105 (BRUSH ROLL)
A # 6 106 (TRIANGLE OPEN)
NOTES
• Instrument names listed in parentheses can only be controlled by MIDI data
received from another keyboard or MIDI control device. It is not possible to play
or transmit these instruments directly from the keyboard.
