T O O L S M O D E
D O C U C O L O R 2 0 6 0 / 2 0 4 5 S Y S T E M A D M I N I S T R A T I O N G U I D E
T
O
OL
S
M
OD
E
1–15
Run Calibration
Use the Run Calibration feature if it is visually obvious that the gray balance on
your scan to print jobs is not correct. During the Run Calibration procedure, the
digital press creates a Look Up Table by reading the 12 Toner Density Patches
that print out. The digital press then compares those readings to the factory-set
target values and makes the necessary adjustments to bring the values within
the target range.
NOTE: PG is an abbreviation for Pattern Generator. The R in 200R indicates
Rotated Line screen, and the C in 200C and 150C indicates Cluster Dot screen.
1
Touch the Run Calibration button on the Auto Color Calibration screen to begin
the calibration process. The Run Calibration screen appears.
Figure 13. Run Calibration screen
