TABLE 12: HEATING CAPACITIES - 4 TON (BHP048)
CFM
RETURN
AIR °F
CAP
1
& KW
OUTDOOR AIR TEMPERATURE, °F (72% RH)
-10
0
10
20
30
40
50
60
1200
55
MBH
13.911
17.096
21.021
25.859
31.821
39.170
48.226
59.388
KW
2.342
2.568
2.795
3.022
3.249
3.476
3.703
3.930
70
MBH
11.264
14.449
18.374
23.212
29.174
36.523
45.579
56.741
KW
2.726
2.952
3.179
3.406
3.633
3.860
4.087
4.314
80
MBH
9.676
12.861
16.786
21.624
27.586
34.935
43.991
55.153
KW
3.067
3.293
3.520
3.747
3.974
4.201
4.428
4.655
1600
55
MBH
16.349
19.534
23.459
28.297
34.259
41.608
50.664
61.826
KW
2.408
2.634
2.861
3.088
3.315
3.542
3.769
3.996
70
MBH
13.702
16.887
20.812
25.650
31.612
38.961
48.017
59.179
KW
2.792
3.018
3.245
3.472
3.699
3.926
4.153
4.380
80
MBH
12.114
15.299
19.224
24.062
30.024
37.373
46.429
57.591
KW
3.133
3.359
3.586
3.813
4.040
4.267
4.494
4.721
2000
55
MBH
17.629
20.814
24.739
29.577
35.539
42.888
51.944
63.106
KW
2.502
2.728
2.955
3.182
3.409
3.636
3.863
4.090
70
MBH
14.982
18.167
22.092
26.930
32.892
40.241
49.297
60.459
KW
2.886
3.112
3.339
3.566
3.793
4.020
4.247
4.474
80
MBH
13.394
16.579
20.504
25.342
31.304
38.653
47.709
58.871
KW
3.227
3.453
3.680
3.907
4.134
4.361
4.588
4.815
1.
These capacities are net capacities - the indoor motor heat has been added. These power inputs are total power inputs - the indoor motor watts have
been added.
