Xerox C15 - Manual (Page 65)

Printer Problems
Chapter 5: Troubleshooting ❖ 5-9
Windows NT 4.0
To align print cartridges under Windows NT 4.0:
Windows 3.1x
To align print cartridges under Windows 3.1x:
1 Select the Xerox DocuPrint Cartridge Utility from the Xerox
DocuPrint C15 program group.
2 Click the Continue button.
3 Select Align.
4 Click OK and follow the alignment instructions.
1 Double click the Main icon in the Program Manager.
2 Double Click the Print Manager icon.
3 Select the DocuPrint C15 printer driver from the list.
4 Select Options/Printer Setup from the menu bar.
5 Select the DocuPrint C15 printer from the list.
6 Select the Setup button.
7 Click the Paper/Output Tab and click on the Printer Monitor
button.
8 Select the Printer Care tab.
9 Click on the Align button and follow the alignment
instructions.
