Back panel switch and connectors description – ZyXEL Communications omni.net LCD series User Manual
Page 10
omni.net LCD series Quick Start Guide
1-6
Back Panel Switch and Connectors Description
ON/OFF
This is the ON/OFF switch.
POWER
This is the 16V-AC power input socket. Plug your AC power adapter into
this socket.
To DTE
This is your serial port RS-232 cable interface. Connect your serial port
cable to this interface.
USB
This is a USB (Universal Serial Bus) interface. Connect your USB cable
to this interface.
ISDN
This is an ISDN RJ-45 terminal interface. Connect your ISDN cable to
this interface.
PHONE 1
This is an analog port #1 RJ-11 terminal jack interface. Connect your
telephone, fax, answering machine or analog line to this interface.
PHONE 2
This is an analog port #2 RJ-11 terminal jack interface. Connect your
telephone, fax, answering machine or analog line to this interface.
