Chapter 3 Wizard Setup
P-660RU-T v2 User’s Guide
44
Figure 10 Internet Connection with PPPoA
The following table describes the labels in this screen.
Table 8 Internet Connection with PPPoA
LABEL DESCRIPTION
User Name Enter the login name that your ISP gives you.
Password Enter the password associated with the user name above.
IP Address This option is available if you select Routing in the Mode field.
A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not
fixed; the ISP assigns you a different one each time you connect to the Internet.
Click Obtain an IP Address Automatically if you have a dynamic IP address;
otherwise click Static IP Address and type your ISP assigned IP address in the IP
Address text box below.
Connection Select Connect on Demand when you don't want the connection up all the time and
specify an idle time-out (in seconds) in the Max. Idle Timeout field. The default
setting selects Connection on Demand with 0 as the idle time-out, which means the
Internet session will not timeout.
Select Nailed-Up Connection when you want your connection up all the time. The
ZyXEL Device will try to bring up the connection automatically if it is disconnected.
Network
Address
Translation
This option is available if you select Routing in the Mode field.
Select None, SUA Only or Full Feature from the drop-sown list box. Refer to
Chapter 12 on page 91 for more details.
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
