P-660RU-T v2 User’s Guide
121
A
P P E N D I X
A
Product Specifications
The following tables summarize the ZyXEL Device’s hardware and firmware features.
Table 35 Hardware Features
Dimensions 111 mm (L) × 106.5 mm (W) × 35 mm (H)
Weight 170g
Power Specification 9VAC 1A
Ethernet Port One auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet Port.
USB Port One USB v1.1 port
Operation Temperature 0º C ~ 40º C
Storage Temperature -20º ~ 60º C
Operation Humidity 20% ~ 85% RH
Storage Humidity 20% ~ 90% RH
Table 36 Firmware Specifications
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Password 1234
DHCP Pool 192.168.1.33 to 192.168.1.64
ADSL Standards Multi-Mode standard (ANSI T1.413,Issue 2; G.dmt(G.992.1);
G.lite(G992.2)).
ADSL2 G.dmt.bis (G.992.3)
ADSL2 G.lite.bis (G.992.4)
ADSL2+ (G.992.5)
Reach-Extended ADSL (RE ADSL)
SRA (Seamless Rate Adaptation)
Auto-negotiating rate adaptation
ADSL physical connection ATM AAL5 (ATM Adaptation Layer type 5)
Multi-protocol over AAL5 (RFC2684/1483)
PPP over ATM AAL5 (RFC 2364)
PPP over Ethernet (RFC 2516)
RFC 1483 encapsulation over ATM
MAC encapsulated routing (ENET encapsulation)
VC-based and LLC-based multiplexing
Up to 8 PVCs (Permanent Virtual Circuits)
I.610 F4/F5 OAM
