coveRInG tHe FolloWInG Models:
yeoMan devon/county 60/county 80
2
aPPlIance coMMIssIonInG cHecKlIst 3
useR InstRuctIons
4
General Points 4
Heating Controls 5
Using the Appliance for the first time 6
Condensation 6
Recommended Fuels 6
Lighting the appliance 7
Running the appliance 7
Burning Tips 9
Ash Removal 10
Wood Burning Tray 10
Extended burning 11
Over-Firing 11
Chimney Fire 11
General Cleaning 12
Cleaning Glass 12
Chimney Sweeping 12
Care of Stove 12
Seasonal Use 13
Troubleshooting Tips 13
InstallatIon InstRuctIons 14
Technical Specifications 14
Boiler output charts 15
Standard Features 15
Packing List 15
Dimensions 16
sIte ReQuIReMents 17
Flue & Chimney 17
Flue outlet positions 18
Hearth Dimensions 18
Walls Next to Hearth 19
PRe-InstallatIon 20
Flues 20
Ventilation 21
InstallatIon 22
Legal Requirements 22
Installing the Appliance 22
Top Flue Installation 22
Rear Flue Installation 23
Removal of Log Guard 24
Fitting & Removal of Baffle 24
Fitting & Removal of Multi-fuel grate 25
Central Heating System 26
Conventional pipe work system 27
Heating system controls 29
Link up system 29
coMMIssIonInG 30
MaIntenance & seRvIcInG 31
Annual Service 31
Removal of Log Guard 32
Removal of Baffle 32
Removal of Riddling grate 32
Fitting a New Door Glass 32
Fitting a New Door Seal 32
Adjusting Door Hinges 33
Adjusting Door Catch 33
BasIc sPaRe PaRts lIst 34
seRvIce RecoRds 38
contents
warranty
Your Yeoman retailer provides you with a Two Year Warranty
for your new stove. However, this specifically excludes naturally
wearing parts or consumables such glass, firebricks and rope
seal and the use of non-authorized fuel such as petro-cokes.
Furthermore, for the warranty to be valid, your stove must have
been installed in accordance with the manufacturer’s instructions
and the second year’s warranty is dependent on the appliance
being serviced 12 months after installation by a HETAS or other
similarly qualified engineer.
They also provide a Five Year Casting Warranty for the carcass of
all cast iron stoves and the cast iron door of steel stoves. Again, this
excludes naturally wearing cast parts such as grate, dampers, log
retainers and baffles.
You can help your retailer to provide their warranties by returning
the reply card or registering online at yeoman-stoves.co.uk.
