Page 11: Component location, Front view
1 Welcome
Xerox Phaser 3200MFP
1-3
Getting to know your machine
Component location
These are the main components of your machine:
Front View
Document
Guide
Document
Input Tray
Document
Cover
Automatic
Document Feeder
Paper Output
Extension
Document
Output Tray
Manual Tray
Control Panel
Document Glass
Paper Input
Tray
Front Door
Output Tray
(Face Down)
Print Cartridge
