Printer components and options
3-10 System Overview Guide
Stitcher/stacker
The stitcher/stacker inserts wire-stitches (staples) into
documents.
Figure 3-7. 4850/4890/92C NPS/IPS printer with stitcher/
stacker
1. Sample tray
2. Stitcher/stacker tray
Sample tray Used for sample prints, rejected prints, and transparencies.
Holds up to 100 sheets of 20-pound or 80 gsm bond.
Stitcher/stacker
tray
Used for output that is stitched (stapled) and/or offset. The tray
holds up to 2000 sheets of unstitched 20-pound or 80 gsm bond,
or an equally high stack of stitched sets (200 two-sheet sets). A
stitched set consists of up to 50 sheets of 20-pound or 80 gsm
bond. The wire supply provides up to 32000 staples.
NOTE: Mixed paper sizes are not supported for stitching. If your
system has a stitcher/stacker, the printer cycles down when it
detects any specification for stitching different-sized papers.
1
2
