Troubleshooting
Unusual Printer/Lmainator Events
980541-001 Rev. A
P640i Card Printer User Guide
25
Laminate not parallel with card edges
•
Skew adjust (mechanical adjustment). Reference
•
If using partial width laminate, edge guide not properly installed (one of two positons).
Section 2
•
Transfer guide not properly installed. Section 2
•
Laminate patch wrapped around heated roller. Page 3-3
Laminate wrinkling
•
Can occur at end of roll. Remove
cassette. If nearly out, discard. Install
fresh roll.
•
If not end-of-roll problem, suspect
obstructions in laminate feed path.
Unusual Printer/Lmainator
Events
Color ribbon runs for longer than 2 or 3
seconds when cover is closed (MEDIA
light stays on)
•
Color ribbon not in ribbon sensor. Section 2
•
Both ribbon cores not fully engaged on arbors. Section 2
•
Ribbon not secured to takeup core. Section 2
•
No ribbon type or wrong ribbon type specified in Printer Properties. Reference
ALARM light stays ON after error condition is cleared
•
Main cover interlock switch may not have actuated when cover closed. Reference
•
Alarm condition(s) not corrected.
Card has both front and back images printed on same side
•
Check selections made in Printing Preferences > Card Setup. Reference
•
Card failed to flip. Run Flip Test 3 to check flip action. Reference
MEDIA light ON steady, but no obvious visual problem
•
Color ribbon not in ribbon sensor. Section 2
•
Color ribbon supply and/or takeup cores not engaging properly on arbors. Section 2
•
Cleaning cassette not engaging properly on the takeup drive. Section 2
•
See Laminator spot check, page 3-3
Note •
There is a delay after closing the cover before the ALARM
light goes out.
